1715L 17" Touchscreen Monitor (Discontinued January 2010)
Overview
The 1715L touchmonitor is designed, developed and built to provide the most cost-effective touch solutions for system integrators and VARs. It packs Elo quality and reliability into an integrated, affordable touchmonitor.
Other features.
- Entry-level monitor with Elo quality
- "Designed for touch" features such as a stable tilt stand
- Long-lasting product cycle
- Sealed touchscreen
- Dual serial/USB interface
- Removable stand and VESA mounting option
- Mounting holes on stand bottom for tabletop security
- Controls on the side rather than the front, plus lockout function for public use
- Digital on-screen display (OSD)
- Worldwide agency approvals
规格
-
技术
产品料号
AccuTouch (Antiglare, Americas, EMEA) - E537168
Acoustic Pulse Recognition (Antiglare, Americas, EMEA) - E324654
IntelliTouch (Antiglare, Americas, EMEA) - E292567
AccuTouch (Antiglare, Asia/Pacific) - E279752
Acoustic Pulse Recognition (Antiglare, Asia/Pacific) - E512399
IntelliTouch (Antiglare, Asia/Pacific) - E892987外壳颜色
深灰色
触控技术
五线电阻 (AccuTouch®) - 单点触控
SAW (IntelliTouch®表面声波) - 单点触控
声学脉冲识别 - 单触对角线
17 英寸对角线，有源矩阵 TFT LCD (LED)
长宽比
5:4
有效显示区域 (mm)
13.3" x 10.6" / 338mm x 270mm
分辨率
1280 x 1024 at 60 Hz
其他支持的分辨率
1280 x 1024 at 60 or 75 Hz
1280 x 960 at 60 Hz
1152 x 864 at 75 Hz
1024 x 768 at 60, 65 Hz (Sun), 70 or 75 Hz
832 x 624 at 75 Hz (Mac)
800 x 600 at 56, 60, 72 or 75 Hz
720 x 400 at 70 Hz
720 x 350 at 70 Hz
640 x 480 at 60, 66 Hz (Mac), 72 or 75 Hz可视角度
水平: ±80° 或 160° 总计 / 垂直: ±80° 或 160° 总计
色彩
1620万
亮度 (标准)
LCD panel: 280 nits
AccuTouch: 230 nits
Acoustic Pulse Recognition: 258 nits
IntelliTouch: 258 nits响应时间 - 总计 (标准)
25 msec
对比度
800:1
触控界面
Dual serial/USB: E537168, E292567, E279752, E892987
USB: E324654, E512399屏幕显示 (OSD)
Controls (side): menu, up, down, select, power
Settings: contrast, brightness, H/V position, RGB (color temp), clock, phase, recall
Languages: English, German, Spanish, Japanese, French
Lockouts: power, user controls视频输入格式
Analog VGA
视频输入信号接口
Mini D-Sub 15-Pin VGA type
功耗 (标准)
50 W
电源
Internal AC, Optional external DC (power brick)
输入电压
AC: 100-240 VAC, 50/60 Hz; DC: +12 VDC ±5%
输入接口
AC: IEC 60320 C6; DC: Coaxial power jack (2 mm pin diameter, 6.4 mm barrel diameter, 8.8 mm barrel length)
输入频率
Horizontal: 31.5-80 kHz / Vertical: 56.3-75 Hz
显示器尺寸 (含底座)
15.4" x 4.4" x 8.0" / 391mm x 366mm x 203mm
运输尺寸
17.99" x 17.32" x 11.42" / 457mm x 440mm x 290mm
重量 (不含包装)
15.2 lbs / 6.9 kg
重量 (含包装)
21.2 lbs / 9.6 kg
工作温度
0°C to 40°C / 32°F to 104°F
储存温度
-20°C to 60°C / -4°F to 140°F
湿度
Operating: 20%-80%
Storage: 10%-90%
noncondensing密封性
Touchscreen sealed to bezel
Touchscreen sealed to LCDMTBF
50,000小时演示
底座选项
Tilt, removable
安装选项
100 mm VESA mount
Threaded-through mounting holes, under stand其他功能
Security lock receptacle
质保
3年
背光灯寿命
Typical 40,000 hours to half brightness
机构认证
North America/Worldwide: UL, cUL, S, MPR II, FCC, CE, VCCI, IC, C-Tick
Asia: UL, cUL, S, MPR II, FCC, CE, VCCI, IC, C-Tick, MIC, CCC, BSMI, China RoHSAC电源线
A North American power cable is included with the part numbers available in the regions other than EMEA. European and UK AC power cables are included with the part numbers available for the EMEA region.AC power cables for power brick are also available at additional cost:
United States: Elo p/n - E042259
Europe: Elo p/n - E690013
United Kingdom: Elo p/n - E235317可选电源适配器
The monitor may also be powered with DC voltage. An optional 12V DC power brick, Elo p/n: E785134, is available at additional cost.
可选 IntelliTouch 手写笔
D82064-000, available at additional cost.
触控/视频线:
Detachable touch and video cables are included.
可选外设
磁条阅读器 (深灰色 MSR) – Elo P/N: E963462
