1825L 18.1" Touchscreen Monitor (Discontinued January 2004)
Overview
The 1825L features a very bright panel with a 170°x170° viewing angle and support for both analog and digital (DVI-D) video inputs. This "designed for touch" monitor has a choice of touch technologies and is extremely stable when touched. Besides being a top quality LCD, the 1825L carries UL/cUL 2601-1/C22.2 No. 601.1, CE MDD EN60601-1, and TÜV medical certifications for North America and Europe, and can be activated with a gloved hand-a critical capability for medical applications.
Other features.
- High quality panel with 170°x170° viewing angle
- Analog and digital (DVI-D) video inputs
- "Designed for touch" features such as a stable tilt base (-5° from vertical to 90° horizontal)
- Cables hidden from user's view
- Mounting holes on base bottom for tabletop security
- Base removable or reversible for wall mounting, plus VESA mounting option
- Built-in speakers located in display head
- Available with AccuTouch® Five-Wire Resistive Technology or IntelliTouch® Surface Wave Technology and serial or USB interface
- Sealed touchscreen
- UL2601 and CE MDD medical approvals
- Controls on the side rather than the front, plus lockout function for public use
- Multilingual on-screen display (OSD) with extras including speaker volume, treble, bass, and balance
- Long-lasting product cycle
- Worldwide agency approvals
规格
-
技术
产品料号
AccuTouch (Antiglare, Worldwide) - F76629-000
AccuTouch (Antiglare, Worldwide) - E77380-000
IntelliTouch (Antiglare, Worldwide) - A31744-000
IntelliTouch (Antiglare, Worldwide) - F30617-000外壳颜色
深灰色
触控技术
五线电阻 (AccuTouch®) - 单点触控
SAW (IntelliTouch®表面声波) - 单点触控对角线
18.1" diagonal, Active matrix TFT LCD
长宽比
4:3
有效显示区域 (mm)
14.1" x 11.3" / 359 mm x 287mm
分辨率
1280 x 1024 at 75 Hz
其他支持的分辨率
1280 x 1024 at 60 or 75Hz
1280 x 960 at 60Hz
1152 x 864 at 75Hz)
1024 x 768 at 65Hz (Sun)
1024 x 768 at 60, 70, or 75Hz (VESA)
832 x 624 at 75Hz (Mac)
800 x 600 at 56, 60, 72, or 75Hz (VESA)
720 x 400 at 70Hz
720 x 350 at 70Hz
640 x 480 at 72 or 75Hz (VESA)
640 x 480 at 66Hz (Mac)
640 x 480 at 60Hz可视角度
水平: ±85° 或 170° 总计 / 垂直: ±85° 或 170° 总计
色彩
1670万
亮度 (标准)
LCD panel: 235 nits
AccuTouch: 188 nits
IntelliTouch: 210 nits响应时间 - 总计 (标准)
Tr: 16 msec; Tf: 7 msec
对比度
400:1
视频输入格式
Analog (no proprietary video card needed); Digital Video Input (DVI-D)
视频输入信号接口
Mini D-Sub 15-Pin; DVI-D 24 pin
触控界面
Serial: F76629-000, A31744-000
USB: E77380-000, F30617-000电源
External power supply
输入电压
100-240 VAC, 50-60 Hz
输入频率
Horizontal: 31.5-80 kHz / Vertical: 56.3-75 Hz
功耗 (标准)
50 W max.
扬声器
Two built-in, rear-facing 1W speakers in display head
屏幕显示 (OSD)
OSD lockouts for power and user controls
OSD extras include volume, treble, bass, balance用户控件
Side: menu, up, down, select, power
OSD: contrast, brightness, H/V position, color, temperature, clock, phase, recall, OSD time
Languages: English, German, Spanish, Italian, Japanese, French
OSD disable/enable: power, volume, and/or OSD menu显示器尺寸 (含底座)
17.5" x 17.5" x 9.4" / 444mm x 445mm x 238mm
重量 (不含包装)
15.9 lbs / 7.2 kg
重量 (含包装)
21.8 lbs / 9.9 kg
工作温度
0°C to 40°C
储存温度
-20°C to 60°C
湿度
Operating: 20-85%
Storage: 5%-95%
noncondensing安装选项
100 mm or 75 mm M4 VESA mount
100 mm M5 threaded holes on base bottom for table top security
Removable base
Reversible stand for wall mounting
Stand rotates from -5° (from vertical) to 90° (horizontal)
Optional stability plate背光灯寿命
40,000 hours to half brightness
质保
3年
机构认证
FCC, VCCI, C-Tick, BSMI Class B, UL, cUL Medical UL 2601-1, C22.2 No. 601.1 (IPX0), CE Medical Device Directive EN60601-1, TÜV Medical IEC 60601-1, MPRII, CB Medical IEC 60601-1. Includes EMC requirements EN, IEC 60601-1-2.
电源线
A North American power cable and a European power cable are included. For touchmonitors being shipped to the United Kingdom, add a UK power cable at no cost by specifying - Elo p/n: 276875-000.
Stability Plate
Mounts to the pedestal of the monitor to increase stability. Elo p/n: D47582-000. Available at additional cost.
