2020L 20" Touchscreen Monitor (Discontinued September 2013)
Overview
The 2020L touchmonitor is designed for retail POS, industrial, and government applications as well as interactive digital signage. The large display area is suitable for many different environments, including flight simulators, industrial equipment, interactive digital signage, and retail.
Other features.
- Available with AccuTouch® Five-Wire Resistive Technology or IntelliTouch® Surface Wave Technology and serial or USB interface
- High quality panel with 178° viewing angle
- Available in black or beige
- Can be used in portrait mode
- Adjustable height
- Carrying handle for easy transport
- Quick release stand
- Desktop stand can be removed or reversed for wall mounting option
- VESA mounting option
- Sealed touchscreen
- Controls on the front
- Digital on-screen display (OSD)
规格
-
技术
产品料号
AccuTouch (USB, Antiglare, Americas, EMEA, Asia/Pacific) - E485292
AccuTouch (Serial, Antiglare, Americas, EMEA, Asia/Pacific) - E280071
AccuTouch (USB, Antiglare, Americas, EMEA, Asia/Pacific) - E479134
AccuTouch (Serial, Antiglare, Americas, EMEA, Asia/Pacific) - E840737
IntelliTouch (USB, Antiglare, Americas, EMEA, Asia/Pacific) - E802828
IntelliTouch (Serial, Antiglare, Americas, EMEA, Asia/Pacific) - E261690
IntelliTouch (USB, Antiglare, Americas, EMEA, Asia/Pacific) - E380894
IntelliTouch (Serial, Antiglare, Americas, EMEA, Asia/Pacific) - E757587外壳颜色
Black or Beige
触控技术
五线电阻 (AccuTouch®) - 单点触控
SAW (IntelliTouch®表面声波) - 单点触控对角线
20.1" diagonal, Active matrix TFT L
长宽比
4:3
有效显示区域 (mm)
16.1" x 12.1" / 410mm x 308mm
分辨率
1600 x 1200 at 60 Hz
其他支持的分辨率
1600 x 1200 at 60 Hz
1280 x 960 at 60 Hz
1280 x 1024 at 60-85 Hz
1200 x 1600 at 60 Hz
1152 x 864 at 70-85 Hz
1152 x 870 at 75 Hz
1024 x 768 at 60-85 Hz
832 x 624 at 75 Hz
800 x 600 at 56-85 Hz
720 x 400 at 70-85 Hz
640 x 480 at 60-85 Hz
640 x 400 at 70-85 Hz (digital)可视角度
水平: ±89° 或 178° 总计 / 垂直: ±89° 或 178° 总计
色彩
1670万
亮度 (标准)
LCD panel: 280 nits
AccuTouch: 238 nits
IntelliTouch: 266 nits响应时间 - 总计 (标准)
16 msec
对比度
700:1
Touch Interfaces
Serial: E280071, E840737, E261690, E757587
USB: E485292, E479134, E802828, E380894屏幕显示 (OSD)
located on the front
视频输入格式
Analog VGA, DVI, DVI-D, DVI-I
视频输入信号接口
Mini D-Sub 15-Pin VGA type, DVI-D, DVI-I
功耗 (标准)
50W
电源
Internal AC
输入电压
AC 100–120V; AC 220–240V
输入接口
AC: IEC 60320 C14
输入频率
Horizontal: 31.5–91.1 kHz / Vertical: 50–85 Hz
显示器尺寸 (含底座)
17.3" x 22.3" x 9.7" / 439mm x 566mm x 247mm
运输尺寸
12.99" x 22.01" x 22.01" / 330mm x 559mm x 559mm
重量 (含底座)
24.3 lbs / 11.0 kg
运输重量 (含底座)
34.0 lbs / 15.4 kg
工作温度
5°C to 35°C / 41°F to 95°F
储存温度
-10°C to 60°C / 14°F to 140°F
湿度
Operating: 30%-80%
Storage: 10%-85%
noncondensing密封性
Touchscreen sealed to bezel
Touchscreen sealed to LCDMTBF
40,000 – 50,000 hours
底座选项
Removable, reverse (wall mount), adjust height, pivot (landscape/portrait mode), quick release
安装选项
100 mm VESA mount
Wall mounting solutions available via third party purchase质保
3年
机构认证
FCC, CE, UL
可选 IntelliTouch 手写笔
D82064-000, available at additional cost.
